Description:

• In an axial-flow pump the pumping medium flows through the impeller in the axial direction.
• In axial-flow pumps, the pressure build-up is not achieved by the centrifugal force but like the aerodynamic principle, by the propeller blade.
• A temperature sensor measures the water temperature.
• The flow rate is measured with an electromagnetic flow meter.
• They are not self-priming and the propeller must always be covered by the pumping medium.
• Axial propeller pumps are used when high flow rates and a small head are needed.
• The closed water circuit means that the trainer can be used independently of the water system.
• The trainer is equipped with measuring elements for the pressures at the inlet and outlet of the pump.
• The typical areas of application for propeller pumps are drainage systems, wastewater treatment plants and cooling water supply systems.

Specification:

• Pump Output: 1000W at 1000min-1
• Max. Flow rate: 700L/min
• Max. Head: 1,75m
• Tank: 160L

Measuring ranges:

• flow rate: 01200L/min
• Temperature: 0100C
• Pressure (inlet): 1bar
• Pressure (outlet): 00,6bar
• Power Supply:230V, 50Hz, 1 phase
• Dimension: 1110x800x1380mm
• Weight: approx.:154kg
