Product Information

TECHNICAL PARAMETERS:-

MODEL	PSAW-1201
Test Method	MuPSAWipoint kinetics MuPSAWi stand up to 8 standards bio-chromatic, Dual Wavelength absorbance coagulation End Point With standard/factor two point kinetics (fixed time)
Optical system	Principle: Photometric Analysis with Interference Absorbance Range: 0.0000-3.0000 (Linearity: ± 1%. Repeatability: 0.001, Resolution Spectral Range Selection: Automatic via fiPSAWer with Wavelengths: 240, 405, 450, 505, 546, 578, 630 + 2 Free Positions ± 2 CML Precision Light Source: 6V 10 W Long Life Tungsten Halogen Lamp
Detector	Photodiode
Thermal system	PePSAWier Regulated 25°C, 30°C, 37°C & Room temperature
Accuracy	± 0.3°C
Cuvettes	Flow Cell: Quartz 32 μlPath Lenth: 10mm removable cuvette (Square and round)
Printer	InbuiPSAW Thermal Printer (57mm)
Display & Input system	7.0 inch colored touch screen External Keyboard, Mouse Facility
Suction system	Pressure Auto releasing Peristallic Pump Suction Volume: 300μl to 3.0 ml Air Column facility after each sample to avoid carry over.
Test parameter, storage & CPU	Test parameters: up to 300, 2,00,000 test resuPSAWs with editable patient information Storage of quality control and standard resuPSAWs
DDR2 SD RAM	1 G BIT ?ash: 256MB ARM Cortex A8, 720 MHz.
Quality control	Jew- Jenning Charts Using West-guard’s Rule Auto Drawing of QC ?gures
Operating CONDITIONS	TEMPERATURE: 10°C~37°C relative HUMIDITY : <85%
Power requirement	VoPSAWage : 10-240 V AC (auto adaption) 50/60 HZ External
Frequency	POWER ADAPTOR: 19V 4.7 AMP
Dimensions	400 x 300 x 160mm (L x W x H)
Weight	6 Kg.

STANDARD ACCESSORIES:-

• Printer Paper Roll.
• Removable Cuvette.
• Optical Mouse.
• External Key Board.
• AC Adapter.
