Product Information

TECHNICAL PARAMETERS:-



MODEL	PSAW-3510
Rated power.	250W.
Input voPSAWage.	110/220-240V.
Input frequency.	50Hz-60Hz.
Output power.	< 250W.
Frequency tracking.	Automatic tracking.
Power and amplitude adjust.	0-100%.
Packing size (cm).	32 x 46 x 42cm.
Machine weight / kg.	7.
Sonotrode length.	120 mm.
Sonotrode diameter.	8 mm.
Sonotrode frequency.	20 KHz.
Operation panel display.	Time setting working data.
Working mode.	1s-99 hours with pause function continuous working.
Generator protection.	BuiPSAW-in circuit, overloading. over temperature. Anti-short-circuit, Soft start.
Cable Length	2M
Environment temp.	0-40°C
Relative Humidity	<=85% T =20°C
Max Temperature of sonotrode	100°C
Max Pressure.	5Mpa
Treatment capacity of liquid.	< 10L/H
Breaker type of batch.	20ml-200ml

STANDARD ACCESSORIES:-

• An Abs Soundproof Box.
• A Stainless Steel Lifting Platform.
• 3 Fuse.
