Specification:

• Provides consistent boring.
• Durable and reliable tool.
• Accuracy in making hole.
• Can drill maximum of 25 mm.
• Creates less noise and less vibration.
• Requires less or low maintenance but provides excellent machining performance.

Technical Specifications:

• Machine Capacity (mm): 25 mm
• Column Dia. (mm): 92 mm
• Table Travel: 480 mm
• Spindle Travel (mm): 250 mm
• Main Electrical Motor: 1 H. P.
• No. of Spindle Speed: 8
• Table Size (mm): 330 x 330 mm
• Center of Spindle to column (mm): 250 mm
• Distance Spindle to Table (mm): 645 mm, 660 mm
• Distance Spindle to Base (mm): 1000 mm, 1045 mm
• Distance from Spindle Centre to (mm): 250 max
• Base Sie (Machined Area) (mm): 255 x 310 mm
• Overall Height with guard (mm): 1780 mm
• Range of Spindle speed (RPM): 70-2000, 130-2600
