Viscosity And Particle Drag
- The balance assembly is an articulated parallelogram, linked to a load cell.
- The balance assembly is mounted on a carrier that runs along the rails of the Flume.
- The parallelogram resists bending moments so that only the force on the model is transmitted to the load cell.
- The display unit displays the force measured by the load cell.
- This unit is hung on the flume.
